Grade 220 Aryl Polyamide Wrapped Aluminum Round, Flat Wire

Grade 220 aryl polyamide (Aramid NOMEX®) wrapped aluminum round, flat wire can be used for transformer,welder,electrical reactor,etc.

contact info

product description

Features of Grade 220 Aryl Polyamide Wrapped Aluminum Round, Flat Wire

1. High dielectric strength

2. Good thermal stability

3. Smooth winding

Material of Grade 220 Aryl Polyamide Wrapped Aluminum Round, Flat Wire

National standard bare aluminium wire or extruded bare aluminum flat wire, smooth surface, small resistance

NOMEX® paper produced by Dupont company

Standard of Grade 220 Aryl Polyamide Wrapped Aluminum Round, Flat Wire

Part of the criteria for adaptation or reference are:

GB/T5584-99

NEMA-MW60-A

Application of Grade 220 Aryl Polyamide Wrapped Aluminum Round, Flat Wire

The wrapping material is made of Dupont NOMEX®410 paper, and its properties have been tested to the strictest extent. Corrosion resistance, radiation resistance, low temperature performance is good, not sensitive to moisture. Good mechanical toughness, and it can be wound upright. Some typical applications include:

Transformer

Welder

Electric reactor

Typical performance of Grade 220 Aryl Polyamide Wrapped Aluminum Round, Flat Wire

The following values do not apply to customized specifications

Test Standard requirements
Specification Round wire:Ø0.3 mm—Ø3.0 mm
Flat wire:a side 0.8—5.0mm;b side 2.0—16mm
Resistivity 0.02785Ω.mm2/m
Breakdown voltage Above 1500V
Thermal shock The minimum thermal shock temperature is 240℃
Softening breakdown 400℃,2min without breakdown
Appearance Wrap firmly, closely, evenly, without wrinkles
Packaging Wood tray packaging, length can be customized

Description:

The bare wire is extruded wire with smooth surface and low resistance, which has obvious advantages over the flat wire produced by traditional drawing process. This product has a variety of wrapping methods to adapt to different working environments.
